Cadence Unveils 12.8 Gbps Gen2 DDR5 MRDIMM IP Validated on TSMC N3

Cadence launches DDR5 12.8 Gbps MRDIMM Gen 2 IP on TSMC N3, targeting soaring Artificial Intelligence data center demands.

Cadence has announced the industry´s first DDR5 12.8 Gbps MRDIMM Gen 2 memory IP system solution, validated on TSMC´s advanced N3 process. This new offering directly addresses the escalating requirements for higher memory bandwidth in enterprise and data center applications driven by Artificial Intelligence workloads, including those supporting cloud-based Artificial Intelligence deployments. The architecture builds on Cadence´s established DDR5 and GDDR6 product lines, promising scalability and adaptability for next-generation system demands.

The DDR5 MRDIMM Gen 2 IP solution delivers a comprehensive memory subsystem by integrating both a PHY and a high-performance controller. In recent hardware validation with Gen 2 MRDIMMs, the solution achieved a top-tier 12.8 Gbps data rate, effectively doubling the bandwidth found in standard DDR5 6400 Mbps DRAM modules. Features such as ultra-low latency encryption and advanced reliability, availability, and serviceability (RAS) underline Cadence´s commitment to robust, high-speed memory design, ensuring security and data integrity at scale.

Designed to support advanced system-on-chips (SoCs) and chiplets, the DDR5 MRDIMM Gen 2 IP offers flexible floor plan options to accommodate different integration requirements while allowing application-specific tuning for power and performance optimization. Engagements with leading customers in Artificial Intelligence, high-performance computing (HPC), and data centers underscore the solution´s early traction and leadership in advancing memory technology. The launch signals a significant step forward for hardware designers seeking to address the throughput and reliability challenges of modern data-driven infrastructures.
